Standard Low Profile / Level Access

Sizes Available

Click sizes for actual base measurements & drain location

Note: More sizes available in Full Height & Mid Height
Low profile shower bases are also available in custom sizes

Low Profile Shower Bases are often used when either: 1) stepping into high tub or over a tall shower curb is too difficult, or, 2) when a more contemporary look is desired.

Standard bases have radius corners and water channel webbing.

Low Profile Design
Low Profile Draining

Standard Low Profile Curb height is 1 1/4” to 2 1/8” tall. All curbs have a slope back into the shower area and the shower area has a 1/4” per foot slope towards the drain.

Standard Low Profile Shower Bases are available individually and also as a kit with our Onyx wall panels. Other shower wall systems such as ceramic tile can also be used with Onyx shower bases.

Onyx Shower Kits can be ordered in 78”, 84”, 90”, 96”, 102”, and 108” tall heights (and any other height as needed – kit height includes base and walls). These kits include the shower base, all wall panels, adhesive silicone, and also color match seam-fill silicone.

Shower Kit

base, walls, and all silicone

48" x 48" Standard

All Standard Low Profile Shower Bases we have available are listed on this page. Other standard bases include: Mid Height, Full Height, Neo-Angle, Double Threshold, or Ramp Style showers, available on their respected pages. For custom sizes or configurations, visit the Popular Shower Configuration page, where you will discover infinite possibilities.

The Onyx Collection gives you a choice of over 45 colors and 75 standard base sizes so you don’t have to settle for something you really don’t want. For a distinctive look, several different Trim options are available, as well as contrasting Stripes and Borders and even Graphic Inlays to enhance the beauty and uniqueness of your shower.

The Onyx Collection also provides a wide range of accessories including Soap Dishes, Shampoo Caddies, Towel Bars, Shower Seats and even Foot Shelves, displayed on the Accessories page.

Add-On Ramp for Low Profile Shower Base

  • Turns any Low Profile Base into a Ramped Base
  • Can be attached permanently, temporarily, or left unattached or removable
  • Finished on left and right ends, top and front edge
  • Can be ordered any length

Low Profile Shower Installation

  • Shower base installed directly on top of the flooring
  • Shower base installed on the subfloor
  • Flooring and underlayment can be run up to the curb
  • This will make the curb height “lower”

Level Access Shower Installation

  • Subfloor is taken out
  • 2x4s are scabbed onto the side of the floor joists, ¾” down
  • Subfloor is placed on the 2x4s, flush with the top of the floor joists
  • Subfloor is taken out
  • Floor joists are notched
  • Subfloor is replaced

Product Certification: ANSI standard, Slip Coefficient, and ASTM E-84 Flame.

For the State of Massachusetts – Plumbing Approval Codes:

To view details of the Massachusetts Approval Codes P-2023-348, P3-0117-357 and P1-0814-9, start by clicking on this link to open the relevant webpage.

Once there, locate the “Manufacturer’s Name First Letter” section and select ‘T’ from the drop-down menu. Next, move to the “Manufacturers” section, choose “The Onyx Collection,” and then click on the “Search” button. This action will display a list of Onyx products related to the approval codes in the Search Results section of the page.
